• Manufacturer of Strenx 700 MC Plates in different lengths or cut to size at distributor price

• Steel plates can be made up of various grades of steel. These grades are divided according to their properties. S700MC Steel Plate is one such type of plate that has good weldability and bending properties. It is heat-treated using a tempering and quenching process. These s700mc plates are widely used in demanding load-bearing structures. It is a high-yield structural steel grade produced in compliance with EN 10149. The S700MC Steel Plate is available in 3350mm in width and 14630 in length. They are available in hot rolled structured steel that is made from cold forming.

• EN 10149-2 S700MC steel plates have a guaranteed high yield strength that helps in reducing the weight through downgauging.  Therefore when weight reduction is required in the conventional structural steel grade these S700MC High Yield Steel plates are used. It is easy to weld these plates and this reduces transportation costs as well. When compared to standard steel grades the superior steel grades such as Strenx 700 MC Plates allow a significant improvement to wear resistance. Many a time these EN 10149-2 Grade S700MC Plates are economical and easier to process.

• EN 10149-2 S700MC High Yield Structural Steels Plates are ideally used in aerial platforms, telescopic handlers, truck trailers, and telescopic cranes. Emphasis is given on strength and weight reduction properties. 700 Heavy Steel Plates should be welded with welding energy of up to 1.5 kJ/cm per mm of thickness. This helps in preserving the mechanical properties of the base metal. If proper care of S700 MC Steel Plates is not taken then the heat affected zone may become soft. The extent of softening and the width of the soft zone depend on the heat applied during welding. Lower heat inputs are recommended in  S700 MC EN 10149-2 structural steel Plates when joint strength and toughness are prioritized.

General Product Description

The high-strength structural steel at 650-700 MPa

Strenx™ 700 is a structural steel with a minimum yield strength of 650-700 MPa depending on thickness.

Strenx 700 meets the requirements of EN 10 025-6 for the S690 grade and thicknesses. Typical applications include demanding load-bearing structures.

Strenx 700 E (complies with S 690 QL) is available in plate thicknesses of 4–160 mm, while Strenx 700 F (complies with S 690 QL1) is available in plate thicknesses of 4–130 mm.

Benefits include:

• Superior bendability and surface quality

• Weldability with excellent HAZ strength and toughness

• Exceptional consistency within a plate guaranteed by close tolerances

• High impact toughness which provides for good resistance to fractures

Dimension Range

Strenx 700 E is available in plate thicknesses of 4 – 160 mm and Strenx 700 F is available in plate thicknesses of 4 - 130 mm. Both grades are available in widths up to 3350 mm and lengths up to 14630 mm depending on thickness. More detailed information on dimensions is provided in the dimension program
